Beta 520 for Harness Products

The Beta 520 Series is the closest thing to leather in the equine marketplace. Since its inception in 1999, the Beta 520 Series has steadily gained the trust of halter makers and tack makers alike. See our colors and profiles for Beta 520 options.

Great for: Reins

Color Options

BL520 Beta Black 520 - BL520
Beta Black 520 - BL520
*All colors shown are digital representations and may vary from actual coating color.

Width and Profile Options

Width Profile Thickness Break Strength (* See footnote below) Buckle Pull Strength (** See footnote below)
1/2" (12.7 mm) profile cross section
B10 Standard
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
1/2" (12.7 mm) profile cross section
B10 Grooved
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
1/2" (12.7 mm) profile cross section
B10 Super Heavy
.140" - .160"
3.56mm - 4.06mm
1000lbs (453.592kg) 200lbs (90.719kg)
5/8" (15.875 mm) profile cross section
B10 Standard
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
5/8" (15.875 mm) profile cross section
B10 Grooved
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
5/8" (15.875 mm) profile cross section
B10 Super Heavy
.140" - .160"
3.56mm - 4.06mm
1000lbs (453.592kg) 200lbs (90.719kg)
3/4" (19.05 mm) profile cross section
B10 Standard
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
3/4" (19.05 mm) profile cross section
B10 Grooved
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
3/4" (19.05 mm) profile cross section
B10 Super Heavy
.140" - .160"
3.56mm - 4.06mm
1000lbs (453.592kg) 200lbs (90.719kg)
7/8" (22.225 mm) profile cross section
B10 Standard
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
7/8" (22.225 mm) profile cross section
B10 Grooved
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
7/8" (22.225 mm) profile cross section
B10 Super Heavy
.140" - .160"
3.56mm - 4.06mm
1000lbs (453.592kg) 200lbs (90.719kg)
1" (25.4 mm) profile cross section
B10 Standard
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
1" (25.4 mm) profile cross section
B10 Grooved
.095" - .105"
2.41mm - 2.67mm
1000lbs (453.592kg) 200lbs (90.719kg)
1" (25.4 mm) profile cross section
B10 Super Heavy
.140" - .160"
3.56mm - 4.06mm
1000lbs (453.592kg) 200lbs (90.719kg)
* Break strength value is per inch of width. Example 2″ (50.8mm) is 2000lbs (907.1847kg) or 3/4″ (19.05mm) is 750lbs (340.194kg).
** All Buckle Pull Strength values are based on a 1″ wide specimen.

Also available in 1 1/4" (31.75mm), 1 1/2" (38.1mm), 2" (50.8mm) widths for reins
