Buy a Sample Roll
All sample sales are final & non-refundable - Free Shipping to Continental U.S. Only! No P.O. Boxes! No International Orders!
-
B05UT200BL231-BSEM-T200A
$71.40 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 days)
:Fair
Opti-Cide3® Immersion (3 days)
:Good
Diversey Oxivir® 1 Immersion (3 days)
:Not recommended
Diversey Virex® Tb Immersion (3 days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial Assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial Assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT200BL231-BSEM-T200A
$71.40 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,700 pounds force
Width (inch)
:1.900 (1.860 - 1.935)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B15TF200BL231-BSEM-T200A
$85.00 / per 50’ roll
Min Break Strength (ASTM D5035)
:2,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF200BL231-BSEM-T200B
$89.50 / per 50’ roll
Min Break Strength (ASTM D5035)
:3,500 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B30SF200BL231-BSEM-T200B
$96.90 / per 50’ roll
Min Break Strength (ASTM D5035)
:5,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss:
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT200BL401-BSEM-A200A
$69.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss:
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT200BL401-BSEM-A200A
$69.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,700 pounds force
Width (inch)
:1.900 (1.860 - 1.935)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B15TF200BL401-BSEM-T200A
$82.45 / per 50’ roll
Min Break Strength (ASTM D5035)
:2,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF200BL401-BSEM-A200B
$86.80 / per 50’ roll
Min Break Strength (ASTM D5035)
:3,500 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B30SF200BL401-BSEM-T200B
$94.05 / per 50’ roll
Min Break Strength (ASTM D5035)
:5,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT200BL520-BSEM-T200A
$65.65 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT200BL520-BSEM-T200A
$65.65 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,700 pounds force
Width (inch)
:1.900 (1.860 - 1.935)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B15TF200BL520-BSEM-T200A
$78.15 / per 50’ roll
Min Break Strength (ASTM D5035)
:2,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF200BL520-BSEM-T200B
$82.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:3,500 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT200BL583-BSEM-T200A
$67.80 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT200BL583-BSEM-T200A
$67.80 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,700 pounds force
Width (inch)
:1.900 (1.860 - 1.935)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B15TF200BL583-BSEM-T200A
$80.70 / per 50’ roll
Min Break Strength (ASTM D5035)
:2,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF200BL583-BSEM-T200B
$85.00 / per 50’ roll
Min Break Strength (ASTM D5035)
:3,500 pounds force
Width (inch)
:1.965 (1.920 - 2.010)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B30SF200BL583-BSEM-T200B
$92.10 / per 50’ roll
Min Break Strength (ASTM D5035)
:5,500 pounds force
Width (inch)
:1.900 (1.840 - 1.950)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT200BL601-BSEM-T200A
$110.65 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,700 pounds force
Width (inch)
:1.900 (1.860 - 1.935)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPV / 70A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:81.7
Glass Transition Temp °C (ASTM E1356)
:-62.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (0)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT100BL231-BSEM-T100A
$44.50 / per 50’ roll
Min Break Strength (ASTM D5035)
:500 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT100BL401-BSEM-A100A
$43.15 / per 50’ roll
Min Break Strength (ASTM D5035)
:500 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT100BL231-BSEM-T100A
$44.50 / per 50’ roll
Min Break Strength (ASTM D5035)
:650 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT100BL401-BSEM-A100A
$43.15 / per 50’ roll
Min Break Strength (ASTM D5035)
:650 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT100BL520-BSEM-T100A
$40.90 / per 50’ roll
Min Break Strength (ASTM D5035)
:650 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT100BL583-BSEM-T100A
$42.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:650 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF100BL231-BSEM-T100B
$47.70 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF100BL401-BSEM-A100B
$46.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF100BL520-BSEM-T100B
$43.90 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF100BL583-BSEM-T100B
$45.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,000 pounds force
Width (inch)
:0.975 (0.940 - 1.010)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT112BL231-BSEM-T112A
$62.20 / per 50’ roll
Min Break Strength (ASTM D5035)
:600 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B05UT112BL401-BSEM-A112A
$60.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:600 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT112BL231-BSEM-T112A
$62.20 / per 50’ roll
Min Break Strength (ASTM D5035)
:900 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT112BL401-BSEM-A112A
$60.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:900 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT112BL520-BSEM-T112A
$57.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:900 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT112BL583-BSEM-T112A
$59.10 / per 50’ roll
Min Break Strength (ASTM D5035)
:900 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF112BL231-BSEM-T112B
$65.40 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,500 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Prop 65
:Coming soon
REACH
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF112BL401-BSEM-A112B
$63.45 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,500 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF112BL520-BSEM-T112B
$60.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,500 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10SF112BL583-BSEM-T112B
$62.20 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,500 pounds force
Width (inch)
:1.460 (1.420 - 1.500)
Thickness (inch)
:0.060 (0.055 - 0.065)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT034BL231-BSEM-T034A
$37.90 / per 50’ roll
Min Break Strength (ASTM D5035)
:400 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT034BL401-BSEM-A034A
$36.70 / per 50’ roll
Min Break Strength (ASTM D5035)
:400 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT034BL520-BSEM-T034A
$34.80 / per 50’ roll
Min Break Strength (ASTM D5035)
:400 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT034BL583-BSEM-T034A
$35.95 / per 50’ roll
Min Break Strength (ASTM D5035)
:400 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF034BL231-BSEM-T034B
$40.35 / per 50’ roll
Min Break Strength (ASTM D5035)
:700 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF034BL401-BSEM-A034B
$39.10 / per 50’ roll
Min Break Strength (ASTM D5035)
:700 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF034BL520-BSEM-T034B
$37.15 / per 50’ roll
Min Break Strength (ASTM D5035)
:700 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF034BL583-BSEM-T034B
$38.35 / per 50’ roll
Min Break Strength (ASTM D5035)
:700 pounds force
Width (inch)
:0.730 (0.710 - 0.750)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF012BL231-BSEM-T012B
$37.20 / per 50’ roll
Min Break Strength (ASTM D5035)
:500 pounds force
Width (inch)
:0.490 (0.475 - 0.505)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF012BL401-BSEM-A012B
$36.10 / per 50’ roll
Min Break Strength (ASTM D5035)
:500 pounds force
Width (inch)
:0.490 (0.475 - 0.505)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT300BL231-BSEM-T300A
$112.50 / per 50’ roll
Min Break Strength (ASTM D5035)
:2,000 pounds force
Width (inch)
:2.955 (2.900 - 3.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT300BL401-BSEM-A300A
$109.15 / per 50’ roll
Min Break Strength (ASTM D5035)
:2,000 pounds force
Width (inch)
:2.955 (2.900 - 3.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10UF300BL231-BSEM-T300A
$139.50 / per 50’ roll
Min Break Strength (ASTM D5035)
:3,750 pounds force
Width (inch)
:2.985 (2.930 - 3.040)
Thickness (inch)
:0.055 (0.051 - 0.059)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10UF300BL401-BSEM-A300A
$135.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:3,750 pounds force
Width (inch)
:2.985 (2.930 - 3.040)
Thickness (inch)
:0.055 (0.051 - 0.059)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT400BL231-BSEM-T400A
$153 / per 50’ roll
Min Break Strength (ASTM D5035)
:1,700 pounds force
Width (inch)
:3.955 (3.900 - 4.010)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240):
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 days)
:Fair
Opti-Cide3® Immersion (3 days)
:Good
Diversey Oxivir® 1 Immersion (3 days)
:Not recommended
Diversey Virex® Tb Immersion (3 days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial Assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial Assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10UF400BL231-BSEM-T400A
$179.65 / per 50’ roll
Min Break Strength (ASTM D5035)
:4,000 pounds force
Width (inch)
:3.985 (3.930 - 4.040)
Thickness (inch)
:0.055 (0.051 - 0.059)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 days)
:Fair
Opti-Cide3® Immersion (3 days)
:Good
Diversey Oxivir® 1 Immersion (3 days)
:Not recommended
Diversey Virex® Tb Immersion (3 days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial Assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial Assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10UF400BL401-BSEM-A400A
$174.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:4,000 pounds force
Width (inch)
:3.985 (3.930 - 4.040)
Thickness (inch)
:0.055 (0.051 - 0.059)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT038BL231-BSEM-T038A
$33.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:150 pounds force
Width (inch)
:0.380 (0.365 - 0.395)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT038BL401-BSEM-A038A
$32.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:150 pounds force
Width (inch)
:0.380 (0.365 - 0.395)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF038BL231-BSEM-T038B
$35.55 / per 50’ roll
Min Break Strength (ASTM D5035)
:375 pounds force
Width (inch)
:0.380 (0.365 - 0.395)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF038BL401-BSEM-A038B
$34.50 / per 50’ roll
Min Break Strength (ASTM D5035)
:375 pounds force
Width (inch)
:0.380 (0.365 - 0.395)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT058BL231-BSEM-T058A
$36.10 / per 50’ roll
Min Break Strength (ASTM D5035)
:250 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT058BL401-BSEM-A058A
$35.05 / per 50’ roll
Min Break Strength (ASTM D5035)
:250 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT058BL520-BSEM-T058A
$33.25 / per 50’ roll
Min Break Strength (ASTM D5035)
:250 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B07UT058BL583-BSEM-T058A
$34.30 / per 50’ roll
Min Break Strength (ASTM D5035)
:250 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.035 (0.030 - 0.040)
Coating Type / Hardness (ASTM D2240)
:PVC / 82A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Natural
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:Coming soon
Glass Transition Temp °C (ASTM E1356)
:Coming soon
Clorox® Healthcare Bleach Immersion (3 Days)
:Good
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Poor
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:Coming soon
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF058BL231-BSEM-T058B
$38.65 / per 50’ roll
Min Break Strength (ASTM D5035)
:575 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 78A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:65.7
Glass Transition Temp °C (ASTM E1356)
:-47.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Fair
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF058BL401-BSEM-A058B
$37.45 / per 50’ roll
Min Break Strength (ASTM D5035)
:575 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:TPU / 90A
Coating Color / Gloss
:Black / High Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:75.8
Glass Transition Temp °C (ASTM E1356)
:-47.3
Clorox® Healthcare Bleach Immersion (3 Days)
:Poor
Opti-Cide3® Immersion (3 Days)
:Fair
Diversey Oxivir®1 Immersion (3 Days)
:Not Recommended
Diversey Virex® Tb Immersion (3 Days)
:Fair
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
-
B10TF058BL520-BSEM-T058B
$35.55 / per 50’ roll
Min Break Strength (ASTM D5035)
:575 pounds force
Width (inch)
:0.615 (0.595 - 0.635)
Thickness (inch)
:0.050 (0.045 - 0.055)
Coating Type / Hardness (ASTM D2240)
:PVC / 60A
Coating Color / Gloss
:Black / Low Gloss
Coating Texture
:Sand Emboss
Webbing Color
:Black
Elongation at Break (ASTM D5035)
:Coming soon
90° Flex Test Room Temp (pounds force)
:Coming soon
90° Flex Test Cold Temp (pounds force)
:Coming soon
Static COF - Steel Sled (ASTM D1894)
:Coming soon
Kinetic COF - Steel Sled (ASTM D1894)
:Coming soon
Coating Adhesion (ISO 2411)
:Coming soon
Hexbar Abrasion (ASTM D6770)
:Coming soon
Taber Abrasion (ASTM D4060)
:Coming soon
Accelerated Weathering (ASTM G155)
:Coming soon
Vicat Softening Temp °C (ASTM D1525)
:55.3
Glass Transition Temp °C (ASTM E1356)
:-55.5
Clorox® Healthcare Bleach Immersion (3 Days)
:Excellent
Opti-Cide3® Immersion (3 Days)
:Good
Diversey Oxivir®1 Immersion (3 Days)
:Fair
Diversey Virex® Tb Immersion (3 Days)
:Good
Biocompatibility - Cytotoxicity (ISO 10993)
:Pass (2)
Biocompatibility - Irritation (ISO 10993)
:Coming soon
Resistance to Fungi (ASTM G21)
:Coming soon
Antibacterial assessment - E. coli (ISO 22196)
:Coming soon
Antibacterial assessment - S. aureus (ISO 22196)
:Coming soon
Regulatory
:
DISCLAIMER: Properties of BioThane® test results were compiled at BioThane Coated Webbing Corp. The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made to its accuracy, suitability for particular applications, or the results to be obtained there from. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end-product performance. Because of the variations in methods, conditions, and equipment used commercially in processing materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end-product performance are the responsibility of the user. SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE.
-
